Lasermet Slim Jim LED Sign – Thin Profile Laser Warning Sign
Lasermet Slim Jim LED Sign is an ultra-thin backlit LED warning sign for laser installations and other environments where clear warning or status information is required. With a depth of only 11 mm, it provides a discreet and professional appearance.
Slim Jim is particularly suitable for installations where a compact sign mounted close to the wall is preferred, such as beside doors and entrances to laser controlled areas.
Only 11 mm Thick
The extremely thin construction is one of the key features of Slim Jim. At approximately 11 mm deep, the sign is ideal where a larger enclosure would be undesirable.
Direct Mains Connection
Slim Jim is available for 230 VAC or 110 VAC operation and runs directly from the mains supply. No additional power supply or transformer is required.
The design is compatible with standard electrical back boxes and conduit boxes, helping to simplify installation.
Different Messages and Colours
A range of standard messages is available for applications including laser status, access control and room status. Custom wording and graphics can also be supplied.
Text and graphics are displayed in a single colour, with red, yellow or blue available.
Finish Options
The standard surround has a white powder-coated finish. A stainless-steel version is also available for installations where a different appearance or finish is required.
Technical Data
- Overall dimensions: 355 × 105 × 11 mm
- Sign dimensions: 275 × 58 mm
- Depth: only 11 mm
- Supply: 230 VAC at 40 mA
- Alternative supply: 110 VAC at 80 mA
- Colours: red, yellow or blue
- Standard surround: white powder-coated finish
- Optional surround: stainless steel
- Messages: standard or customised
For Laser Areas and Industrial Environments
Slim Jim can be used at entrances to laser controlled areas, laboratories, production cells and other controlled environments where laser status or access information needs to be clearly displayed.
The sign can be incorporated into a wider laser safety installation together with interlock systems and other safety components.
Contact LMI AB About LED Warning Signs
LMI AB can help you select the appropriate warning sign, message and configuration according to the safety requirements and environment of your laser installation.
Contact us for advice regarding LED warning signs and complete laser safety solutions.
